קדם מגבר לפטיפון PHONOb מבית KARAN ACUOSTICS

Technical specifications

The following data were consistently measured on random test objects and are typical of the product in question.
PHONO INPUTS: LINE OUTPUTS:

PHONO EQ SETTINGS:

OUTPUT IMPEDANCE: OUTPUT LEVEL:

GAIN:

FREQUENCY RESPONSE: DISTORTION:

SPEED:
SIGNAL TO NOISE RATIO:

AC VOLTAGE:
AC VOLTAGE RANGE: POWER CONSUMPTION:

WARRANTY: NETDIMENSIONS:
NET WEIGHT: PACKAGEDIMENSIONS: PACKAGE WEIGHT:
2 (1 x Single-Ended RCA + 1 x Balanced XLR) 2 (1 x Single-Ended RCA + 1 x Balanced XLR)
RIAA:
EMI: DECCA: COLUMBIA: TELDEC:
+/- 0.1dB +/- 0.15dB +/- 0.15dB +/- 0.15dB +/-0.1dB
90 Ohm
1.55 V/RMS (nominal)
18.0 V/RMS (maximum / balanced / 600 Ohm load)

from 48 to 71dB (multiple internal adjustments available, please see GAIN SETTINGS page of this manual)

20 Hz to 20 kHz, +/-0 dB; (1.5 Hz to 1 MHz, -3 dB) THD 0.003% (Full output, 20Hz to 20kHz)
IMD 0.003% (Full output)
Rise and Settling time < 450 ns

Slew rate 1.500 V/us (Amplification stages) > 90 dB (Phono MM), > 81 dB (Phono MC)

115 V or 230 V (nominal line voltage) +/- 10% (from nominal line voltage) 60 W (maximum)

5 years, parts and labor

504x141x390mm(whd); 19.8x5.6x15.3inch(whd) (Main control unit)
16.6 kg / 36.3 lbs
(Main control unit)

645x255x516mm(whd); 25.5x10.2x20.4inch(whd) (Main control unit)
26.5 kg / 57.9 lbs - (Main control unit)
