קדם מגבר לפטיפון PHONOa מבית KARAN ACUOSTICS

Technical specifications

PHONOINPUTS: 6(3xSingle-EndedRCA+3xBalancedXLR)

LINEOUTPUTS: 2(1xSingle-EndedRCA+1xBalancedXLR)

PHONOEQSETTINGS: RIAA: +/-0.1dB

EMI: +/-0.15dB

DECCA: +/-0.15dB

COLUMBIA: +/-0.15dB

TELDEC: +/-0.1dB

OUTPUTIMPEDANCE: 90Ohm

OUTPUTLEVEL: 1.55V/RMS(nominal)

 V/RMS 18.0V/RMS(maximum / balanced / 600 Ohm load)

GAIN: from48to71dB(multipleinternaladjustmentsavailable

please see GAIN SETTINGS page of this manual)

FREQUENCY RESPONSE: 20 Hz to 20 kHz, +/-0 dB; (1.5 Hz to 1 MHz, -3 dB)

DISTORTION: THD0.003%(Fulloutput,20Hzto20kHz) IMD 0.003% (Full output)

SPEED: RiseandSettlingtime<450ns Slew rate 1.500 V/us (Amplification stages)

SIGNAL TO NOISE RATIO: > 90 dB (Phono MM), > 81 dB (Phono MC)

ACVOLTAGE: 115Vor230V(nominallinevoltage)

ACVOLTAGERANGE: +/-10%(fromnominallinevoltage)

POWERCONSUMPTION: 60W(maximum)

WARRANTY: 5years,partsandlabor

NETDIMENSIONS: 504x141x390mm(whd);19.8x5.6x15.3inch(whd) (Main control unit and Power supply unit)

NETWEIGHT: 15.0kg/32.8lbs-(Maincontrolunit) 17.1 kg / 37.5 lbs - (Power supply unit) P

PACKAGE DIMENSIONS: 645x255x516mm(whd);25.5x10.2x20.4inch(whd) (Main control unit and Power supply unit)

PACKAGE WEIGHT: 25.0kg/54.6lbs-(Maincontrolunit) 27.0 kg / 59.4 lbs - (Power supply unit)
